ECOWATER Commercial Heavy Duty 2″ Valve Water Filter

Effective and Efficient Water Filters

• Innovative 2" Eco Flow-Pack Valve
• Electronic Demand Control Module
• Fully Programmable
• Safe 24-Volt Electronics
• Non-Volatile Memory
• Turbine Flow Meter
• Washed Quartz Underbedding
• Exceptional Flow Rates
• Automatic Bypass During Backwash
• Fiberglass Reinforced Resin Tank
• Self-Cleaning Distributors
• Regeneration Frequency Programmable
• High-Strength, Non-Corrosive Piston
• Lockout Feature to Prevent Unauthorized Changes
• Water Totalizer to Keep Track of Volume History

Activated Carbon Filters
The activated carbon filters offer an effective method to remove chlorine taste and odor and
other organic substances in a water supply. Small amounts of color and low levels of hydrogen
sulfide may also be removed with activated carbon. In some difficult water conditions, it may
be necessary to use a different grade of carbon other than the standard grade.

Multi-Media Filters
The multi-media filters provide an efficient means to remove sediment and particulate
matter from a water supply. Multi-media filters use stratified layers of graduated size media
which offer a depth filtration process through the filter. The larger particles are filtered out at
the top of the media and the bottom layers filter out particles as small as 10 microns.

Greensand Filters
The greensand filters employ a manganese-coated greensand as the main medium in the filter.
Additional media are used to provide a depth filtration process, similar to the multi-media
filter. The feed water must be treated to provide a continuous oxidation of iron, manganese
and hydrogen sulfide for effective and efficient operation. This requires using a chemical feed
pump to inject potassium permanganate into the supply water.
